Module Scheduler

Core -- SCHEDULER prepares and handles the execution of functions over scheduled time (intervals).

Banner Image

SCHEDULER manages the scheduling of functions:

  • optionally in an optional specified time interval,
  • optionally repeating with a specified time repeat interval,
  • optionally randomizing with a specified time interval randomization factor,
  • optionally stop the repeating after a specified time interval.

Demo Missions

SCHEDULER Demo Missions source code

SCHEDULER Demo Missions, only for beta testers

ALL Demo Missions pack of the last release

YouTube Channel

SCHEDULER YouTube Channel (none)

Contributions:

  • FlightControl : Concept & Testing

Authors:

  • FlightControl : Design & Programming

Global(s)

SCHEDULER

SCHEDULER class, extends Base#BASE

The SCHEDULER class creates schedule.

Type SCHEDULER

SCHEDULER:Clear()

Clears all pending schedules.
SCHEDULER.MasterObject
SCHEDULER:New(SchedulerObject, SchedulerFunction, SchedulerArguments, Start, Repeat, RandomizeFactor, Stop)

SCHEDULER constructor.
SCHEDULER:Remove(ScheduleID)

Removes a specific schedule if a valid ScheduleID is provided.
SCHEDULER:Schedule(SchedulerObject, SchedulerFunction, SchedulerArguments, Start, Repeat, RandomizeFactor, Stop)

Schedule a new time event.
SCHEDULER.ScheduleID

the ID of the scheduler.
SCHEDULER.SchedulerObject
SCHEDULER:Start(ScheduleID)

(Re-)Starts the schedules or a specific schedule if a valid ScheduleID is provided.
SCHEDULER:Stop(ScheduleID)

Stops the schedules or a specific schedule if a valid ScheduleID is provided.

Global(s)

#SCHEDULER SCHEDULER

SCHEDULER class, extends Base#BASE

The SCHEDULER class creates schedule.

A SCHEDULER can manage multiple (repeating) schedules. Each planned or executing schedule has a unique ScheduleID. The ScheduleID is returned when the method SCHEDULER.Schedule() is called. It is recommended to store the ScheduleID in a variable, as it is used in the methods SCHEDULER.Start() and SCHEDULER.Stop(), which can start and stop specific repeating schedules respectively within a SCHEDULER object.

SCHEDULER constructor

The SCHEDULER class is quite easy to use, but note that the New constructor has variable parameters:

The SCHEDULER.New() method returns 2 variables:

  1. The SCHEDULER object reference.
  2. The first schedule planned in the SCHEDULER object.

To clarify the different appliances, lets have a look at the following examples:

Construct a SCHEDULER object without a persistent schedule.

  • SCHEDULER.New( nil ): Setup a new SCHEDULER object, which is persistently executed after garbage collection.

    SchedulerObject = SCHEDULER:New() SchedulerID = SchedulerObject:Schedule( nil, ScheduleFunction, {} )

The above example creates a new SchedulerObject, but does not schedule anything. A separate schedule is created by using the SchedulerObject using the method :Schedule..., which returns a ScheduleID

Construct a SCHEDULER object without a volatile schedule, but volatile to the Object existence...

  • SCHEDULER.New( Object ): Setup a new SCHEDULER object, which is linked to the Object. When the Object is nillified or destroyed, the SCHEDULER object will also be destroyed and stopped after garbage collection.

    ZoneObject = ZONE:New( "ZoneName" ) SchedulerObject = SCHEDULER:New( ZoneObject ) SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {} ) ... ZoneObject = nil garbagecollect()

The above example creates a new SchedulerObject, but does not schedule anything, and is bound to the existence of ZoneObject, which is a ZONE. A separate schedule is created by using the SchedulerObject using the method :Schedule()..., which returns a ScheduleID Later in the logic, the ZoneObject is put to nil, and garbage is collected. As a result, the ScheduleObject will cancel any planned schedule.

Construct a SCHEDULER object with a persistent schedule.

  • SCHEDULER.New( nil, Function, FunctionArguments, Start, ... ): Setup a new persistent SCHEDULER object, and start a new schedule for the Function with the defined FunctionArguments according the Start and sequent parameters.

    SchedulerObject, SchedulerID = SCHEDULER:New( nil, ScheduleFunction, {} )

The above example creates a new SchedulerObject, and does schedule the first schedule as part of the call. Note that 2 variables are returned here: SchedulerObject, ScheduleID...

Construct a SCHEDULER object without a schedule, but volatile to the Object existence...

  • SCHEDULER.New( Object, Function, FunctionArguments, Start, ... ): Setup a new SCHEDULER object, linked to Object, and start a new schedule for the Function with the defined FunctionArguments according the Start and sequent parameters.

    ZoneObject = ZONE:New( "ZoneName" ) SchedulerObject, SchedulerID = SCHEDULER:New( ZoneObject, ScheduleFunction, {} ) SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {} ) ... ZoneObject = nil garbagecollect()

The above example creates a new SchedulerObject, and schedules a method call (ScheduleFunction), and is bound to the existence of ZoneObject, which is a ZONE object (ZoneObject). Both a ScheduleObject and a SchedulerID variable are returned. Later in the logic, the ZoneObject is put to nil, and garbage is collected. As a result, the ScheduleObject will cancel the planned schedule.

SCHEDULER timer stopping and (re-)starting.

The SCHEDULER can be stopped and restarted with the following methods:

  • SCHEDULER.Start(): (Re-)Start the schedules within the SCHEDULER object. If a CallID is provided to :Start(), only the schedule referenced by CallID will be (re-)started.

  • SCHEDULER.Stop(): Stop the schedules within the SCHEDULER object. If a CallID is provided to :Stop(), then only the schedule referenced by CallID will be stopped.

    ZoneObject = ZONE:New( "ZoneName" ) SchedulerObject, SchedulerID = SCHEDULER:New( ZoneObject, ScheduleFunction, {} ) SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {}, 10, 10 ) ... SchedulerObject:Stop( SchedulerID ) ... SchedulerObject:Start( SchedulerID )

The above example creates a new SchedulerObject, and does schedule the first schedule as part of the call. Note that 2 variables are returned here: SchedulerObject, ScheduleID...
Later in the logic, the repeating schedule with SchedulerID is stopped.
A bit later, the repeating schedule with SchedulerId is (re)-started.

Create a new schedule

With the method SCHEDULER.Schedule() a new time event can be scheduled. This method is used by the :New() constructor when a new schedule is planned.

Consider the following code fragment of the SCHEDULER object creation.

ZoneObject = ZONE:New( "ZoneName" )
SchedulerObject = SCHEDULER:New( ZoneObject )

Several parameters can be specified that influence the behaviour of a Schedule.

A single schedule, immediately executed

SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {} )

The above example schedules a new ScheduleFunction call to be executed asynchronously, within milleseconds ...

A single schedule, planned over time

SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {}, 10 )

The above example schedules a new ScheduleFunction call to be executed asynchronously, within 10 seconds ...

A schedule with a repeating time interval, planned over time

SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {}, 10, 60 )

The above example schedules a new ScheduleFunction call to be executed asynchronously, within 10 seconds, and repeating 60 every seconds ...

A schedule with a repeating time interval, planned over time, with time interval randomization

SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {}, 10, 60, 0.5 )

The above example schedules a new ScheduleFunction call to be executed asynchronously, within 10 seconds, and repeating 60 seconds, with a 50% time interval randomization ... So the repeating time interval will be randomized using the 0.5,
and will calculate between 60 - ( 60 * 0.5 ) and 60 + ( 60 * 0.5 ) for each repeat, which is in this example between 30 and 90 seconds.

A schedule with a repeating time interval, planned over time, with time interval randomization, and stop after a time interval

SchedulerID = SchedulerObject:Schedule( ZoneObject, ScheduleFunction, {}, 10, 60, 0.5, 300 )

The above example schedules a new ScheduleFunction call to be executed asynchronously, within 10 seconds, The schedule will repeat every 60 seconds. So the repeating time interval will be randomized using the 0.5,
and will calculate between 60 - ( 60 * 0.5 ) and 60 + ( 60 * 0.5 ) for each repeat, which is in this example between 30 and 90 seconds. The schedule will stop after 300 seconds.

Type Scheduler

Type SCHEDULER

The SCHEDULER class

Field(s)

SCHEDULER:Clear()

Clears all pending schedules.

SCHEDULER.MasterObject
SCHEDULER:New(SchedulerObject, SchedulerFunction, SchedulerArguments, Start, Repeat, RandomizeFactor, Stop)

SCHEDULER constructor.

Parameters

  • #table SchedulerObject : Specified for which Moose object the timer is setup. If a value of nil is provided, a scheduler will be setup without an object reference.

  • #function SchedulerFunction : The event function to be called when a timer event occurs. The event function needs to accept the parameters specified in SchedulerArguments.

  • #table SchedulerArguments : Optional arguments that can be given as part of scheduler. The arguments need to be given as a table { param1, param 2, ... }.

  • #number Start : Specifies the amount of seconds that will be waited before the scheduling is started, and the event function is called.

  • #number Repeat : Specifies the interval in seconds when the scheduler will call the event function.

  • #number RandomizeFactor : Specifies a randomization factor between 0 and 1 to randomize the Repeat.

  • #number Stop : Specifies the amount of seconds when the scheduler will be stopped.

Return values

  1. #SCHEDULER: self.

  2. #number: The ScheduleID of the planned schedule.

SCHEDULER:Remove(ScheduleID)

Removes a specific schedule if a valid ScheduleID is provided.

Parameter

  • #number ScheduleID : (optional) The ScheduleID of the planned (repeating) schedule.

SCHEDULER:Schedule(SchedulerObject, SchedulerFunction, SchedulerArguments, Start, Repeat, RandomizeFactor, Stop)

Schedule a new time event.

Note that the schedule will only take place if the scheduler is started. Even for a single schedule event, the scheduler needs to be started also.

Parameters

  • #table SchedulerObject : Specified for which Moose object the timer is setup. If a value of nil is provided, a scheduler will be setup without an object reference.

  • #function SchedulerFunction : The event function to be called when a timer event occurs. The event function needs to accept the parameters specified in SchedulerArguments.

  • #table SchedulerArguments : Optional arguments that can be given as part of scheduler. The arguments need to be given as a table { param1, param 2, ... }.

  • #number Start : Specifies the amount of seconds that will be waited before the scheduling is started, and the event function is called.

  • #number Repeat : Specifies the interval in seconds when the scheduler will call the event function.

  • #number RandomizeFactor : Specifies a randomization factor between 0 and 1 to randomize the Repeat.

  • #number Stop : Specifies the amount of seconds when the scheduler will be stopped.

Return value

#number: The ScheduleID of the planned schedule.

#number SCHEDULER.ScheduleID

the ID of the scheduler.

SCHEDULER.SchedulerObject
SCHEDULER:Start(ScheduleID)

(Re-)Starts the schedules or a specific schedule if a valid ScheduleID is provided.

Parameter

  • #number ScheduleID : (optional) The ScheduleID of the planned (repeating) schedule.

SCHEDULER:Stop(ScheduleID)

Stops the schedules or a specific schedule if a valid ScheduleID is provided.

Parameter

  • #number ScheduleID : (optional) The ScheduleID of the planned (repeating) schedule.
